FFC1108-1 Alarm 100M Portable Sonar Fish Finders 45 degrees Sonar Coverage Echo

📋 ESPECIFICAÇÕES

• Iluminação traseira: LED branco liga/desliga

• Marca: LUCKYLAKER

• Escolha: sim

• Capacidade de profundidade do FFC1108-1: 328 pés (100 m)

• Capacidade de profundidade do FFCW1108-1: 130 pés (45 m)

• Alcance de detecção: 0,6 a 183 metros

• Tela: LCD TN de 2 polegadas com proteção anti-UV

• Produto químico de alta preocupação: Nenhum

• Idioma: Inglês

• Idiomas do manual: Inglês, Russo, Alemão e Japonês

• Origem: China Continental

• Entrada de energia: AAA

• Fonte de energia: Bateria nº 7 (AAA)

• Requisito de energia: 4 pilhas AAA

• Cobertura do sonar:

  • FFC1108-1: 45 graus

  • FFCW1108-1: 90 graus

  • Ângulo de feixe: 45 graus em 200 kHz (FFC1108-1)

• Frequência do sonar:

  • Cabo: 200 kHz

• Design à prova d’água:

  • Nível 4 (resistente a respingos)

• Semi-escolha: sim

PRODUCT SPECIFICATION OF FFC1108-1:

1) Display: 2inch TN/ANTI-UV LCD 2) Back lighting: White LED 3) Depth Capability: 328feet(100m) 4) Power Requirement: 4xAAA alkaline batteries（not included） 5) Waterproof design: level-4 (spray-water-proof) 6) Show water depth, fish location, and bottom grass & rock 7) User selectable sensitivity,depth units, and fish alarm setting 8) Operational Temperature: 14degF to 122degF(-10degC to 50degC)

1.Adjust the sensor float to be at least 18 centimeters away from the sensor.2.Connect the probe and receiver and place the probe into the water.3.Turn on the receiver.

Detection depth of 100m/328ft

1.Battery strength indicator2.Battery save on/off3.Sensitivity indicator4.Fish alarm on/off5.Backlight on/off6.Set up key7.Power On/ Off8.Water depth indicator9.Fish depth indicator10.Enter key

1.Float2.Transducer3.Cable

Find fish in lakes, ponds and rivers. Cast from dock, shore, bank or kayak.View water depth, water temperature, through a receiver.

1) Display: 2 inch LCD2) Sonar coverage: 45° in 200KHz3) Depth capacity: 0.7M-100M4) Power: 4 x AAA batteries (NOT included)5) Net weight: 163g / 5.7oz6) Operational Temperature: 14°F to 122°F (-10°C to 50°C)

Different fishing ways:

1.Night Fishing Probe 2.Turbid Water Probe 3.Ice Fishing Probe

Attention:

1.Kindly remind that FFC1108-1 has only wired mode, and you cannot match the sensor and monitor randomly. 2.Use fish finder in smooth and hard place (like water tank, swimming pool, water bucket, or fish pond) will cause repeatedly sonar reception, or the the detection can be inaccurate. Please use fish finder in outdoor deep water. 3.The monitor cannot display the size of the fish. 4.Manual:English/German/Russian/Japanese
